MVS-15RHP boligventilatoren er en yderst støjsvag og energibesparende boligventilator! Da denne model ikke kræver en fjernbetjening, er den blandt andet velegnet til renoveringsprojekter, hvor der ikke kan anvendes en jordet stikprop. For at gøre installationen ekstra nem leveres denne MVS-15RHP med en indbygget fugtsensor og en Perilex-stik.
Takket være en række smarte nyheder og den indbyggede fugtsensor fungerer dette Orcon ventilationssystem fuldautomatisk, så manuel betjening ikke er nødvendig. Det gør det nemt at installere systemet i flere forskellige situationer. Ønsker du alligevel manuel betjening? Så kan denne MVS-enhed nemt udvides med RF-betjeninger og/eller sensorer, som CO2-sensorer. MVS-15RHP er den perfekte balance mellem lydniveau, energiforbrug og komfort! Oplev det selv!
| Brand: | Orcon |
| Kategori | Alle mekanisk ventilation |
| GTIN | 8720701074507 |
| Producentens varenummer | 21130010 |
| Artikel nummer | 19130009 |
| Pakke-type | Ventilationsboks |
| Kategorikode | 10 |
| Housing material | Plastic |
| Max. air volume at 50 Pa | 580 m³/h |
| Max. air volume at 100 Pa | 550 m³/h |
| Max. air volume at 150 Pa | 510 m³/h |
| Max. air volume at 200 Pa | 490 m³/h |
| Max. air volume at 250 Pa | 470 m³/h |
| Max. air volume at 300 Pa | 420 m³/h |
| Power consumption at max. air volume at 100 Pa | 80 W |
| Frequency supply voltage (min) | 50 Hz |
| Frequency supply voltage (max) | 60 Hz |
| Supply voltage (min) | 200 V |
| Supply voltage (max) | 240 V |
| Max. nominal current | 0.8 A |
| Sound power level | 46 dB(A) |
| Type of motor | Electronically commutated (EC) |
| Electrical connection | Perilex connecting cable |
| Energy efficiency class | D |
| Control signal | PWM (pulse-width-modulated) |
| Type of speed control | 3 positions |
| Type of switch | Other |
| With wireless remote control | Nej |
| Suitable for wireless remote control | Ja |
| With wired control unit | Nej |
| Suitable for wired control unit | Nej |
| Suitable for requirement-controlled ventilation | Ja |
| With internal humidity (RH) sensor | Ja |
| With external humidity (RH) sensor | Nej |
| Suitable for (extra) humidity (RH) sensor | Ja |
| With internal carbon dioxide (CO2) sensor | Nej |
| With external carbon dioxide (CO2) sensor | Nej |
| Suitable for (extra) carbon dioxide (CO2) sensor | Ja |
| Detects volatile organic compounds | Nej |
| With pressure sensor | Nej |
| Suitable for (extra) pressure sensor | Nej |
| With constant volume flow control | Nej |
| With zone controller | Nej |
| Suitable for zone controller | Nej |
| Operation by app | Nej |
| With movement sensor | Nej |
| Suitable for movement sensor | Nej |
| Sensor controlled air flow | Nej |
| Number of suction connections | 5 |
| Max. number of wet zones | 5 |
| Forbindelse | Insteekeind |
| Nominal duct diameter suction side | 125 mm |
| Nominal duct diameter exhaust air | 125 mm |
| Nominal duct diameter sanitary connections | 125 mm |
| Nominal duct diameter kitchen connections | 125 mm |
| Suitable for wall mounting | Ja |
| Suitable for ceiling mounting | Ja |
| Suitable for mounting in suspended ceiling | Ja |
| Suitable for mounting in an attic | Ja |
| Suitable for floor mounting | Ja |
| Suitable for suspended mounting | Ja |
| Horizontal mounting | Ja |
| Vertical mounting | Ja |
| Rear connection | Ja |
| Dybde | 303 mm |
| Højde | 389 mm |
| Bredde | 449 mm |
| Weight | 4.72 kg |
| Energimærke | D |
| Type stik | Perilex-stik |
